Description
Lens:
IR lens – 3.6mm(F:1.2 ) 3Mega Pixel lens
IR Leds – 3pcs dot
IR distance – 15 Meter
Resolution – 1MP 720P (1280*720)
Image Sensor:
Image Sensor – 8135S+1045
Display Resolution – 720P (1280*720)
Min. Illumination – Low illumination,0.1Lux@ (F1.2, AGC ON),0 Lux with IR On
Audio:
Input/Output – Built in Microphone, 3.5mm audio Jack output
Audio Compression – G.711, ADPCM/32kbps
Video:
Image Compression – H.264
Light Frequency – 50Hz, 60Hz
Image Resolution – 1MP, 1280 x 720(720P)
Image frame rate – 1~25fps
View – H.264 dual streaming
Image adjust – The brightness, contrast, saturation, chromaticity, is adjustable
White balance – Automatic, Indoor, Outdoor, is adjustable
Infrared mode – Automatic, Manual (on/off)
Network:
Ethernet – One 10/100Mbps RJ-45
Supported Protocol – TCP/IP, UDP/IP, HTTP, SMTP, FTP, DHCP, DDNS, UPNP
Wireless Standard – WIFI(IEEE802.11b/g/n)
Data Rate – 802.11b: 11Mbps(Max.) 802.11g: 54Mbps(Max.)
802.11n: 150Mbps(Max.)
Support IP address – Static IP address, dynamic IP address
Hardware Interface:
POWER Interface – DC 12V/1.0A (EU,US,UK adapter or other types optional) – Power Consumption ,3 Watts
Audio Input/Output – 2 Ways talking
Reset Buttons – One Reset
Wireless Interface – WIFI antenna
Environment:
Operate Temp – -20° ~ 55°C (32°F ~ 131°F)
Operate Humidity – 10% ~ 80% non-condensing
Storage Temp – -20°C ~ 60°C(14°F ~ 140°F)
Storage Humidity – 0% ~ 90% non-condensing
Other:
App – YooSee
Angle – 75°
Storage – SD Card (Max 64GB)
IP66 – Waterproof
Certification – CE FCC ROHS ISO9001
